How to Choose the Right Industrial Casters
How to choose the right caster product is a problem for the layman,
here our factory will answer it for you:
1. First of all, the material of the caster wheel must be selected:
usually the wheel material is nylon,
rubber, polyurethane, elastic glue, iron core-wrapped polyurethane,
cast iron, plastic, etc. Polyurethane
wheels can meet your handling requirements regardless of whether
they are running on indoor or outdoor
ground; elastic rubber wheels can be used for hotels, medical
equipment, wooden floors, tile floors and
other grounds that require little noise and quiet when walking;
nylon wheels, The iron wheel is suitable for
the site where the ground is uneven or there are iron filings and
other substances on the ground.
2. How to choose the correct caster bracket: Usually, when choosing
a suitable caster bracket, the first
consideration is the weight of the caster, such as supermarkets,
schools, hospitals, office buildings, hotels
and other places. Because the ground is good, smooth and the goods
handled are lighter, (each The casters
can carry 50-150kg), and it is suitable to choose the
electroplating wheel frame which is stamped and formed
with a thin steel plate of 3-4mm. The wheel frame is light,
flexible in operation, quiet and beautiful. If the beads
are often moved or handled, double-row beads should be used; in
factories and warehouses, where the goods
are frequently transported and the load is heavy (each caster
carries 150-680kg), it is suitable to use thick
steel plate 5-6mm stamping hot forging And welded double-row ball
wheel frame; if it is used to transport
heavy objects such as textile factories, automobile factories,
machinery factories, etc., due to the heavy
load and long walking distance (each caster carries 700-2500kg), it
should be selected to The wheel frame
is welded after cutting the thick steel plate 8-12mm. The movable
wheel frame uses plane ball bearings and
ball bearings on the bottom plate, so that the casters can bear
heavy loads, rotate flexibly, and resist impact.
3. How to calculate the bearing weight of casters: In order to be
able to calculate the load capacity required
by various casters, it is necessary to know the self-weight of the
transport equipment, the maximum load and
the number of single wheels and casters used. The required load
capacity of a single wheel or caster is
calculated as follows: T=(E+Z)/MxN: T= required load capacity of a
single wheel or caster; E= self-weight
of transport equipment; Z= maximum load; M= used single wheel The
number of wheels and casters;
N = safety factor (about 1.3-1.5).
4. Select the diameter of the caster: Usually, the larger the
diameter of the wheel, the easier it is to push,
the greater the load capacity, and the better the protection of the
ground from damage. The selection of the
wheel diameter should first consider the load and the starting of
the truck under the load. thrust to decide.
5. Ensure the rotation flexibility of the wheel: the larger the
single wheel, the more labor-saving it is to rotate,
the needle roller bearing can carry heavier loads, and the
resistance is larger during rotation; the single wheel
is installed with high-quality ball bearings, which can carry
heavier loads and rotate. Lighter, flexible and quiet.
6. Temperature condition of the product: Severe cold and high
temperature have a great impact on the
caster, such as the polyurethane wheel at a low temperature of
minus 45 °C, it can rotate flexibly and
freely, and the high temperature resistant wheel can rotate easily
at a high temperature of 270 °C.
Industrial Swivel Casters Parameter
| Wheel material | Nylon6 |
| Load Capacity | 700KG |
| Wheel Diameter | 75mm |
| Color | white |
| Tread Width | 50mm |
| Load Height | 108MM |
Industrial Swivel Casters Describe
Industrial Swivel Casters Size
Industrial Swivel Casters Material
| Name | Material | Treatment |
| 1 | Caster Seat | Cold-rolled carbon steel | Black Coated/Zn Galvanized |
| 2 | Body | Aluminum alloy | Ivory/Powder Coated |
| 3 | Ball | Bearing Steel | Ni-Cr |
| 4 | Brake | Steel 45 | Zn Galvanized |
| 5 | Pin | Steel 10 | Zn Galvanized |
| 6 | Wheel | PA6 | Black |
Industrial Swivel Casters Scope of application
Application.
Communication equipment, semiconductor manufacturing equipment,
experimental equipment,
medical equipment, printing machines, all kinds of Press, all kinds
of special machinery, all kinds
of variable production equipment, dust-free room equipment,
aluminum frame, equipment, etc.
