How to install caster universal wheel correctly
1, Install 3 casters, including 1 universal wheel and 2 directional
wheels
The installation combination of 1 universal wheel and 2 directional
wheels is suitable for
short-distance handling of low center of gravity, medium and light
equipment, with good directional
control and economy.
2, Install 4 casters, including 2 universal wheels and 2
directional wheels
The combination of two universal wheels and two directional wheels
is a conventional assembly method.
There are two directional wheels in the front and two movable
universal wheels close to the push
handrail in the rear. It is suitable for long-distance and
long-distance transportation of heavy equipment,
which is economical and durable.
3, Install 4 casters, all of which are directional wheels
The 4 directional wheels are of rhombic layout design, which is
suitable for long straight-line
transportation of heavy equipment and cannot be used on sloping
working faces.
4, Install 4 casters, including 2 directional wheels and 2
universal belt brake wheels
Two universal belt brake wheels and two directional wheels are
installed. There are two directional
wheels in the front and two universal belt brake wheels close to
the push handrail in the rear. This
assembly is suitable for long and short distance and sloping roads.
5, Install 4 casters, all universal wheels
The installation method of 4 universal wheels is suitable for
short-distance handling of heavy
equipment. It has excellent directionality and is often used for
turnover work vehicles in factory
workshops.
6, Install 6 casters, including 4 universal wheels and 2
directional wheels
4 universal wheels and 2 directional wheels are suitable for
long-distance handling of heavy equipment
and household countertops. They have good handling and are used for
horizontal contact surfaces.
Industrial Swivel Casters Parameter
| Wheel material | Nylon6 |
| Load Capacity | 700KG |
| Wheel Diameter | 75mm |
| Color | white |
| Tread Width | 50mm |
| Load Height | 108MM |
Industrial Swivel Casters Describe
Industrial Swivel Casters Size
Industrial Swivel Casters Material
| Name | Material | Treatment |
| 1 | Caster Seat | Cold-rolled carbon steel | Black Coated/Zn Galvanized |
| 2 | Body | Aluminum alloy | Ivory/Powder Coated |
| 3 | Ball | Bearing Steel | Ni-Cr |
| 4 | Brake | Steel 45 | Zn Galvanized |
| 5 | Pin | Steel 10 | Zn Galvanized |
| 6 | Wheel | PA6 | Black |
Industrial Swivel Casters Scope of application
Application.
Communication equipment, semiconductor manufacturing equipment,
experimental equipment,
medical equipment, printing machines, all kinds of Press, all kinds
of special machinery, all kinds
of variable production equipment, dust-free room equipment,
aluminum frame, equipment, etc.
